SpotLED 24 silver-grey, 3000K, Spot

Technical data

Input voltage

12-30VDC

Power consumption

500mA@24VDC, 950mA@12VDC

Light output

750 lm

Performance

10 W

Colour temperature

3000 K

Abstrahlwinkel

Spot

Protection rating

IP67

Protection class

III

surface temperature

max. +55°C

Temperature range

-30°C to +45°C

Case material

aluminum housing

Case colour

silver-grey

Optics

5x10°

Width

108 mm

Height

62 mm

Depth

81.5 mm

Weight

0.35 kg

Connector cable

5 m

Connector cable cross-section

3 x 0.25mm²

Connector cable plug

without

Downloads

104976 SpotLED 24 3000K 5x10° PC k Spot

Accessories

Item No: 104431

Protective grid V2A for SpotLED

Item No: 101068

Magnetic clamp, rubberized, round

Ø66 x 8,5 mm, force of 180 N, M6 thread

Item No: 126197

Ground spike 280mm, PA6/GF

complete, incl. screws

Item No: 104508

Transparent cover, for SpotLED

Show all

Spare parts

Item No: 152996

Spare glass (assembly),

polycarbonate transparent
