Underfloor distribution system PIAZZETTA

Technical data

Material

stainless steel V2A

Installation depth (delivery condition)

mind. 1000 mm

Cover

individually fillable

Cable outlet

no

Operating mode cover

open with protection occurs

Inner diameter concrete tube

600 mm

Height concrete tube

1000 mm

Cover heating

optional

Downloads

Dimensional drawing/Scheme

Accessories

Item No: 060122

Top frame / reservoir cover V2A

for Type 600, B125 (12.5 t)

Item No: 014205

Top frame / reservoir cover V2A

for Type 600, C250 (25 t)

Item No: 014311

Connection set 3020 for Underfloor distributor

with clamp web 5x35mm², 2x cable glands M40

Item No: 014313

Connection set 3800 for Underfloor distributor

with clamp web 5x70mm², 2xcable glands M50
