Vesuvio underfloor distributor incl. upper concrete tube,

Technical data

Material

steel casting

Diameter

605 mm

Installation depth (delivery condition)

mind. 610 mm

Cover

cast iron cover

Cable outlet

yes

Operating mode cover

closed

Inner diameter concrete tube

600 mm

Height concrete tube

500 mm

Downloads

Dimensional drawing/Scheme

Accessories

Item No: 010848

Connection set 2516 for Underfloor distributor

system with clamp web 5x16 mm², 2x cable glands M32

Item No: 173776

Locking device kit for VESUVIO

Item No: 010851

Connection set type 3020 for Underfloor system,

with clamp 5x35mm², 2 cable glands M40
